The ESW14 series is comfortable and high secure Straddle Leg Electric Stacker with duplex mast and maximum lifting height 4m, equipped with Geolift-Made EPS and AC drive system.
Standard equipped with 280Ah lead-acid sideway battery. 3 different lowering speed, slow-medium-fast suitable for different situations. Chassis design life up to 10 years. Injection molding cover, Stellana Brand Wheels offer best quality. Geolift-made EPS and Curtis controllers can real-time protect the vehicle control from circuit overvoltage, under voltage, over current, excess temperature, Short circuit. Double controllers can safely reduce the traveling speed under the condition of Mast lifting and sharp turn in the corner. The lifting Limit function can protect hydraulic motor, save energy and battery. Self-made handle can be modified for cold store application.
Straddle Leg Electric Stacker 1.4 Ton
ESW14 Series| Specification | UOM | ESW1420 | ESW1425 | ESW1430 | ESW1433 | ESW1436 | ESW1440 |
|---|---|---|---|---|---|---|---|
| Power Supply / Operation | - | Electric Rider · Stand-on / Walkie | |||||
| Mast Type | - | Standard 2-Stage (Duplex) | |||||
| Loading Capacity (Q) | kg | 1400 | |||||
| Load Center | mm | 600 | |||||
| Lifting Height | mm | 2000 | 2500 | 3000 | 3300 | 3600 | 4000 |
| Min. Fork Height | mm | 65 | |||||
| Mast Lowered Height | mm | 1535 | 1765 | 1980 | 2135 | 2335 | 2500 |
| Extended Mast Height | mm | 2500 | 3000 | 3500 | 3800 | 4100 | 4500 |
| Size of Fork (W × H) | mm | 100 × 40 | |||||
| Fork Length | mm | 1070 | |||||
| Overall Length | mm | 2005 (folded) / 2425 (extended) | |||||
| Overall Width | mm | 1470 | |||||
| Min. Turning Radius | mm | 1565 (folded) / 1975 (extended) | |||||
| Aisle Width (L1000×W1200) | mm | 2260 (folded) / 2585 (extended) | |||||
| Min. Ground Clearance | mm | 50 | |||||
| Travel Speed (Laden/Unladen) | km/h | 6.0 / 6.0 | |||||
| Lifting Speed (Laden/Unladen) | mm/s | 130 / 180 | |||||
| Gradeability (Laden/Unladen) | % | 6 / 8 | |||||
| Driving Motor | kW | AC 1.50 | |||||
| Lifting Motor | kW | DC 1.20 | |||||
| Steering Motor | kW | DC 0.15 | |||||
| Battery Voltage / Capacity | V/Ah | 24 / 280 (lead-acid / maintenance-free option) | |||||
| Steering Type | - | Electric Power Steering (EPS) | |||||
| Brake / Controller | - | Electromagnetic / Regenerative · ZAPI | |||||
| Weight (incl. battery) | kg | 1276 | 1280 | 1285 | 1290 | 1295 | 1300 |
