Environment Friendliness
- zero emission
- low noise
- free of heavy metals
- no corrosion
- no acid mist volatilization
Maintenance Free
- unnecessary of fluid adding and dust proofing
- daily maintenance free
- manual maintenance free
Long Service Life
- Over 75% capacity reserved after 4000 shifts operation
- Longer service life than lead-acid battery in equal working condition
- 5 years or ten thousand hours quality guarantee for high performance lithium battery assembly
High Efficiency and Energy Saving
- 2hours charging meet 6-8 hours working demand
- High-energy density, self-discharging rate lower than 1% per month
- 95% energy conversion rate, superior charging and discharging performance
- Flexible to charge, easy to operate, no impact on battery life
- Unnecessary to change battery, cost saving & operation safety
Suitable for working in both high and low environment
- Lithium battery is better than lead-acid battery when working between -25℃and 55℃
High safety
- According to the characteristics of industrial vehicles, it achieves safety protection design which includes lithium battery materials, battery core type, PACK technique and system power management.
- “Multiple node safety closed circuit protection” realizing truck real-time closed-circuit protection in variable conditions
- “Lock affirming” function during charging avoiding “hot connecting and disconnecting” operation
- “Whole system emergency button” to disconnect the truck control system and BMS power quickly ensuring truck safety
| H2 Series Lithium Battery Forklift 1.5-3.5 ton Specifications | |
|---|---|
| Load Capacity | 1.5 – 3.5 tons |
| Battery Type | Lithium-ion (LiFePO₄) |
| Battery Voltage | 48V / 80V (depending on model) |
| Battery Capacity | 100Ah – 210Ah |
| Lifting Speed | ~0.4 m/s (loaded), ~0.5 m/s (unloaded) |
| Lowering Speed | ~0.5 m/s (with load) |
| Travel Speed |
|
| Gradeability | ~15-20% (with load) |
| Mast Type | Standard 2-stage / 3-stage (free lift available) |
| Lifting Height | 3,000 – 6,000 mm (customizable) |
| Fork Length | 1,070 mm (standard), other sizes optional |
| Fork Adjustment Range | 200 – 1,200 mm |
| Charging Time | 1.5 – 3 hours (fast charging available) |
| Energy Consumption | ~8 – 12 kWh per 8-hour shift (approx.) |
| Overall Length | ~2,300 – 2,800 mm |
| Overall Width | ~1,200 – 1,300 mm |
| Mast Lowered Height | ~2,000 – 2,200 mm |
| Mast Extended Height | ~4,000 – 6,000 mm |
| Wheelbase | ~1,500 – 1,700 mm |
| Weight | ~2,800 – 4,500 kg (depending on capacity & battery size) |
