The EPT30 Series Electric Pallet Truck is a stand-on driving type electric pallet truck suitable for high strength condition use, it provides users with safe, comfortable, reliable logistic solutions. The EPS can reduce the labour intensity. The AC driving motor provides constant strong power and it is maintenance free. Standard equipped with large 270Ah capacity battery to meet customers’ requirement of continuous long working hours. The side-way battery design is convenient for battery replacement.
EPT30 come with Stelling brand wheels which offer best quality. The double controllers equipped to protect the vehicle control circuit over voltage, under voltage, over current, excess temperature or short circuit. The lifting limit function to protect hydraulic motor, save energy and battery.
Performance of EPT30 Series Electric Pallet Truck
- The EPT Series Electric Pallet Truck Ergonomic handle with:
- throttle with infinite forward and reverse speeds
- lift/ lower controls
- belly reverse safety button
- horn
- electromagnetic disk brake with automatic dead-man feature when handle is released.
| Model | UOM | EPT30-N | EPT30-W |
|---|---|---|---|
| Power Supply | Electric | ||
| Type of Operation | Rider | ||
| Loading Capacity | kg | 3000 | |
| Load Center | mm | 600 | |
| Overall Fork Width | mm | 550 | 685 |
| Fork Length | mm | 1150 | 1200 |
| Min. Fork Height | mm | 85 | |
| Max. Fork Height | mm | 200 | |
| Fork Width | mm | 170 | |
| Fork Thickness | mm | 75 | |
| Overall Length | mm | 1916 (folded) / 2333 | |
| Overall Width | mm | 790 | |
| Overall Height (With Handle) | mm | 1455 | |
| Min. Turning Radius | mm | 1746 (folded) / 2158 | |
| Aisle Width (L1000×W1200) | mm | 2077 (folded) / 2458 | |
| Travel Speed (Laden/Unladen) | km/h | 6.0 / 6.0 | |
| Lifting Speed (Laden/Unladen) | mm/s | 30 / 35 | |
| Gradeability (Laden/Unladen) | % | 6 / 16 | |
| Driving Motor | kw | AC 1.50 | |
| Lifting Motor | kw | DC 1.20 | |
| Battery Voltage / Capacity | V/Ah | 24 / 270 | |
| Steering Type | Electric Power Steering (EPS) | ||
| Controller | ZAPI | ||
| Weight | kg | 831 | |
